| Brand Name : | Intel / Altera |
| Model Number : | EP1C6Q240C8N |
| Price : | $Negotiate |
| Payment Terms : | T/T, Western Union, MoneyGram |
| Supply Ability : | 10000-pcs-Mouth |
| Delivery Time : | 3-5 work days |
Ep1c6q240c8 Ic Chip Programmer Ep1c6q240c8n Fpga Field Programmable Gate Array Fpga Cyclone I 598 Labs 185 Ios
Description:
The Cyclone® field programmable gate array family is based on a 1.5-V, 0.13-μm, all-layer copper SRAM process, with densities up to 20,060 logic elements (LEs) and up to 288 Kbits of RAM. With features like phase-locked loops (PLLs) for clocking and a dedicated double data rate (DDR) interface to meet DDR SDRAM and fast cycle RAM (FCRAM) memory requirements, Cyclone devices are a cost-effective solution for data-path applications. Cyclone devices support various I/O standards, including LVDS at data rates up to 640 megabits per second (Mbps), and 66- and 33-MHz, 64- and 32-bit peripheral component interconnect (PCI), for interfacing with and supporting ASSP and ASIC devices. Altera also offers new low-cost serial configuration devices to configure Cyclone devices
Features:
The Cyclone device family offers the following features:
■ 2,910 to 20,060 LEs, see Table 1–1
■ Up to 294,912 RAM bits (36,864 bytes)
■ Supports configuration through low-cost serial configuration device
■ Support for LVTTL, LVCMOS, SSTL-2, and SSTL-3 I/O standards
■ Support for 66- and 33-MHz, 64- and 32-bit PCI standard
■ High-speed (640 Mbps) LVDS I/O support
■ Low-speed (311 Mbps) LVDS I/O support
■ 311-Mbps RSDS I/O support
■ Up to two PLLs per device provide clock multiplication and phase shifting
■ Up to eight global clock lines with six clock resources available per logic array block (LAB) row
■ Support for external memory, including DDR SDRAM (133 MHz), FCRAM, and single data rate (SDR) SDRAM
■ Support for multiple intellectual property (IP) cores, including Altera® MegaCore® functions and Altera Megafunctions Partners Program (AMPPSM) megafunctions.
Date Sheet :
| Product Attribute | Attribute Value |
|---|---|
| Intel | |
| Product Category: | FPGA - Field Programmable Gate Array |
| RoHS: | N |
| 5980 LE | |
| - | |
| 90 kbit | |
| 185 I/O | |
| 1.5 V | |
| 3.3 V | |
| 0 C | |
| + 70 C | |
| SMD/SMT | |
| QFP-240 | |
| Tray | |
| Brand: | Intel / Altera |
| Maximum Operating Frequency: | 250 MHz |
| Moisture Sensitive: | Yes |
| Number of Logic Array Blocks - LABs: | 598 LAB |
| Operating Supply Voltage: | 1.5 V to 3.3 V |
| Product Type: | FPGA - Field Programmable Gate Array |
| Subcategory: | Programmable Logic ICs |
| Total Memory: | 92160 bit |
